BUSINESS MUSIC | INSTALLED | COMPACT M 06 | TWO-WAY PROFESSIONAL SPEAKER | 100 W RMS power handling | Technical Specifications
Technical Specifications
| Acoustical specifications | |
| Frequency Response (-10dB) | 60 Hz - 20000 Hz |
| Max SPL @ 1m | 116 dB |
| Horizontal coverage angle | 120° |
| Vertical coverage angle | 80° |
| Directivity index Q | 7 |
| System Sensitivity | 90 dB |
| Power section | |
| Amplification | Full Range |
| Nominal Impedance | 8 ohm |
| Power Handling | 100 W |
| Peak Power Handling | 400 W PEAK |
| Protections | Dynamic active mosfet |
| Crossover Frequencies | 2200 Hz |
| Recommended Amplifiers | DMA 162, DMA 162P, DMA 504, DMA 82 |
| Transducers | |
| Dome Tweeter | 1 x 1.3'' neo, 1.0'' v.c |
| Woofer | 1 x 6.0'', 1.5'' v.c |
| Input/Output section | |
| Input connectors | Euroblock |
| Output connectors | |
| Standard compliance | |
| Safety agency | CE compliant |
| Physical specifications | |
| Cabinet/Case Material | Plywood |
| Hardware | 4 x M6, 2 x M8 |
| Grille | Steel with clothing |
| Color | Black - RAL 9005, White - RAL 9003 |
| Size / Weight | |
| Height | 365 mm / 14.37 inches |
| Width | 211 mm / 8.31 inches |
| Depth | 232 mm / 9.13 inches |
| Weight | 5.5 kg / 12.13 lbs |
| Shipping information | |
| Package Height | 386 mm / 15.2 inches |
| Package Width | 256 mm / 10.08 inches |
| Package Depth | 235 mm / 9.25 inches |
| Package Weight | 7 kg / 15.43 lbs |
