RCF NX-932A

Save $100
RCFSKU: 13000767

Price:
$1,899 $1,999

Shipping calculated at checkout

Description

Active 12" 2-way Powered Speaker w/ 3" HF

NX 932-A is masterfully engineered from the ground up to deliver stellar audio performance for sound providers, small bands and DJs. The combination of a 3" titanium/neodymium compression driver, 12" woofer - two-channel 2,100W amplifier, and the constant directivity True Resistive Waveguide produces coherent 100° x 70° coverage for the listening area with up to 132 dB SPL, distortion-free sound. Used as a stand-alone speaker for a FOH system, satellite (with subwoofer), stage monitor, or flown speaker, the NX 932-A blends high performance and reliability in a compact package. Merging RCF proprietary FiRPHASE and Bass Motion Control DSP processing, perfectly tuned for each model, the audience will experience absolute sound clarity and deep, powerful bass response. The tour-ready, rugged all-wood cabinet is easy to carry and secure to install on a pole-, flown-, wall-, or truss-mounted using the dedicated rigging points available.

Features:

  • Up to 132 dB Sound Pressure Level
  • 2100W Class-D Bi-Amplification
  • 45-20000 Hz linear frequency response
  • 3" Titanium/Neodymium Compression Driver
  • 12" Woofer
  • FiRPHASE zero degrees phase technology
  • Bass Motion Control woofer excursion management
  • Six M10 and four Quick Lock rigging points


Specifications:
ACOUSTICAL SPECIFICATIONS

  • Frequency Response: 45 Hz ÷ 20000 Hz
  • Max SPL @ 1m: 132 dB
  • Horizontal coverage angle: 100°
  • Vertical coverage angle: 70°

TRANSDUCERS

  • Compression Driver: 1 x 1.4'' neo, 3.0'' v.c
  • Woofer: 12'', 2.5'' v.c

INPUT/OUTPUT SECTION

  • Input signal: bal/unbal
  • Input connectors: Combo XLR/Jack
  • Output connectors: XLR
  • Input sensitivity: -2 dBu/+4 dBu

PROCESSOR SECTION

  • Crossover Frequencies: 700Hz
  • Protections: Thermal, RMS
  • Limiter: Soft Limiter
  • Controls: Linear, Boost, Stage, Volume

POWER SECTION

  • Total Power: 2100 W Peak
  • High frequencies: 700 W Peak
  • Low frequencies: 1400 W Peak
  • Cooling: Convection
  • Connections: Powercon TRUE1 TOP IN/OUT

STANDARD COMPLIANCE

  • Safety agency: CE compliant

PHYSICAL SPECIFICATIONS

  • Hardware: 2 x M10 Top, 1 x M10 each side, 1 x M10 bottom, 1 x M10 rear| 2 each side quick lock pin seat
  • Handles: 1 x Side
  • Pole mount/Cap: Yes
  • Color: Black, White

SIZE

  • Height: 620 mm / 24.41 inches
  • Width: 362 mm / 14.25 inches
  • Depth: 405 mm / 15.94 inches
  • Weight: 22.9 kg / 50.49 lbs
