Description
SUB 18-AX | PROFESSIONAL ACTIVE 18" SUBWOOFER | 2200 Watt Class-D Amplifier | Technical Specifications | 135 dB MAX SPL | 18” Woofer, bass reflex housing
Technical Specifications
| Acoustical specifications | |
| Frequency Response | 35 Hz - 120 Hz |
| Max SPL @ 1m | 135 dB |
| Transducers | |
| Woofer | 1 x 18'', 4.0'' v.c |
| Input/Output section | |
| Input signal | bal/unbal |
| Input connectors | Combo XLR/Jack |
| Output connectors | XLR |
| Input sensitivity | -2 dBu/+4 dBu |
| Processor section | |
| Protections | Thermal |
| Limiter | Soft Limiter |
| Controls | |
| Encoder for Volume control and data entry. Touch Screen for parameter management and monitor. | |
| Power section | |
| Total Power | 2200 W Peak, 1100 W RMS |
| Cooling | Convection |
| Connections | |
| Powercon TRUE1 TOP IN/OUT | |
| Standard compliance | |
| Safety agency | CE compliant |
| Physical specifications | |
| Cabinet/Case Material | Plywood |
| Handles | 1 handle per side |
| Pole mount/Cap | M20 thread |
| Grille | Steel |
| Color | Black, White |
| Size / Weight | |
| Height | 693 mm / 27.28 inches |
| Width | 505 mm / 19.88 inches |
| Depth | 685 mm / 26.97 inches |
| Weight | 42.9 kg / 94.58 lbs |
| Shipping information | |
| Package Height | 735 mm / 28.94 inches |
| Package Width | 745 mm / 29.33 inches |
| Package Depth | 565 mm / 22.24 inches |
| Package Weight | 49 kg / 108.03 lbs |
