22 AWG stranded (0.15 x 19 ) tinned copper conductors, polyethylene insulation, twisted pair, polyethylene inner jacket, Duofoil® (100% coverage) and cotton plus a tinned copper braid shield (85% coverage), PVC jacket.

Conductor: Number of Pairs: 2Total Number of Conductors: 4 (plus 1 ground)AWG: 22Stranding: 0.15 x 19Conductor Diameter: .0354"Conduct or Material: TC-Tinned Copper Insulation: Insulation Material PE Polyethylene Lay Length:Lay Length: 1.1"Direction: Left Hand LayTwists: 10.9 per foot Inner Jacket:Inner Jacket Material: PE- PolyethyleneInner Jacket Diameter: .055"Pair Color Code: Green/Black/Red/White Outer Shield:Outer Shield Trade Name: Duofoil®Outer Shield Type: Tape/Braid Outer Shield Material:Layer Number:1, Material Trade Name: Dufoil®, Type: Tape, Material: Aluminum Foil-Polyester, Coverage %: 100Layer Number: 2, Material Trade Name: Dufoil®, Type: Braid, Material: TC-Tinned Copper, Coverage %: 85 Outer Jacket:Outer Jacket Material: PVC-Polyvinyl Chloride Overall Nominal Diameter:Overall Nominal Diameter: .295" Mechanical Characteristics:Operating Temperature Range: (-30 degrees C To + 75 degrees C)Bulk Cable Weight: 50 lbs/1000Minimum Bend Radius (Install): 3.5"Maximum Recommended Pull Tension: 22 lbs. Electrical Characteristics:Nominal Characteristic Impedence: 110 OhmsNominal Capacitance Conductor to Conductor @ 1KHz: 12.5 pF/f tNominal Cap Cond. To Other Cond. & Shield @ 1KH z: 23 pF/ftNominal Velocity of Propagation: 76%Nominal Delay: 1.6 Nanoseconds per footNominal Conductor DC Resistance @ 20 degrees C: 24 Ohms/1000 ftIndividual Pair Nominal Shield DC Resistance @ 20 degrees C: 15 Ohms/1000 ftNominal Attenuation (dB/100 ft): 0.6 (@ 1 MH) dB/100 ft.Maximum Recommended Current: 2.1 Amps per conductor @ 25 degrees C
