The CS3 BU is the base unit for the CS3 conference system and provides all the necessary inputs and outputs to manage a conference for up to 60 microphone stations. It is the interface to all audio devices in a meeting room and offers a RS232 interface to connect an optional camera control system. The CS3 BU can even work in a stand-alone mode in four selectable operating modes offering maximum flexibility in conference management. With the NOM limitation function, the maximum number of active stations can be programmed to 1, 2, 4 or 6 simultaneous open microphones.

Features

• All in one conference controller
• For discussion systems of up to 60 stations per base unit
• Four selectable operating modes
• For flexible conference management
• Connects to all relevant devices
• e.g. PA, recording, ext. audio and camera control systems
• Compact 19" housing
• For easy rack mounting

Specifications

• Power Supply: SMPS 100-240V (50Hz / 60 Hz) 3A
• Static Consumption: 13W
• Nominal Power Consumption: 320W
• Output Power: ≤90W / 24V each way
• Mode: Balanced / Unbalanced
• Frequency Response: 50Hz-20kHz
• S/N: >80dB
• Harmonic Distortion: <0.5%
• Harmonic Distortion at Overload: <1%
• Crosstalk Attenuation (1kHz): >50dB
• Operating Temperature: 0°C - 40°C at 95% relative humidity (non-condensing)
• Length: 482 mm
• Width: 281 mm
• Height: 88.4 mm
• Weight: 5.2kg
