The DriveCore™ Install series amplifiers is a complete line of high performance installation amplifiers based on the proprietary DriveCore technology. DCi Series amplifiers are designed, engineered and manufactured to the industry’s highest quality standards, and provide system integrators with the advanced features and flexibility required for challenging 21st century installed sound applications. Versatile, compact and highly energy-efficient, DCi Series amplifiers continue the unbroken Crown tradition of leadership in professional and commercial power amplifier technology. Output Power: Dual Mode - All Channels Driven DCi Network Model Channels 2Ω 4Ω 8Ω 16Ω 70Vrms 100Vrms 2|300N 2 150W 300W 300W 150W 300W 300W 4|300N 4 150W 300W 300W 150W 300W 300W 8|300N 8 150W 300W 300W 150W 300W 300W 2|600N 2 300W 600W 600W 300W 600W 600W 4|600N 4 300W 600W 600W 300W 600W 600W 8|600N 8 300W 600W 600W 300W 600W 600W 2|1250N 2 1250W 1250W 1250W 625W 1250W 1250W 4|1250N 4 1250W 1250W 1250W 625W 1250W 1250W 2|2400N 2 2100W 2400W 1900W 950W 2100W 2300W 4|2400N 4 2100W 2400W 1900W 950W 2100W 2300W Minimum Guaranteed Power (20Hz - 20kHz) Output Power: Bridge Mono Mode - All Channels Driven DCi Network Model 4Ω 8Ω 16Ω 140Vrms 200Vrms 2|300N 300W 600W 600W 600W 600W 4|300N 300W 600W 600W 600W 600W 8|300N 300W 600W 600W 600W 600W 2|600N 600W 1200W 1200W 1200W 1200W 4|600N 600W 1200W 1200W 1200W 1200W 8|600N 600W 1200W 1200W 1200W 1200W 2|1250N 2500W 2500W 2500W 2500W 2500W 4|1250N 2500W 2500W 2500W 2500W 2500W 2|2400N 4200W 4800W 3800W 4200W 4600W 4|2400N 4200W 4800W 3800W 4200W 4600W Minimum Guaranteed Power (20Hz - 20kHz)

Features

• ANALOG & DIGITAL INPUTS - With digital audio transport via HARMAN’s proprietary BLU-Link, plus balanced analog inputs, DCi gives you a tremendous audio advantage - at a much lower cost. The priority input router allows you to specify a primary input, and if audio is lost the amp automatically switches to the other input.
• NETWORK MONITORING & CONTROL - Better monitoring, control and audio manipulation with the HiQnet™ protocol that’s over standard TCP/IP. Remotely see how all networked DCi amplifiers are performing and control them as needed. In addition, this allows Audio Architect software and the Powered by Crown app to work with DCi amplifiers.
• PROGRAMMABLE GENERAL PURPOSE INPUT/OUTPUT PORTS - GPIO ports can be configured in many different ways, such as volume controls, recall presets, or to report errors to a master computer.
• DIGITAL SIGNAL PROCESSING - DSP capabilities include the following: LevelMAX Limiters Input/Output EQ Crossover Delay Matrix Mixer Speaker Line Monitoring
• LevelMAX Limiters
• Input/Output EQ
• Crossover
• Delay
• Matrix Mixer
• Speaker Line Monitoring

Specifications

• Model: DCI4X2400N
• Output Channels: 4
• Frequency Response (8Ω, 20Hz - 20kHz): ±0.25dB
• Total Harmonic Distortion (at full rated power, 20Hz - 20kHz): 0.35%
• Damping Factor (20Hz to 100Hz): >5000
• Load Impedance (Stereo/Dual Mode): 2Ω - 16Ω; 70Vrms and 100Vrms
• Load Impedance Bridge Mono: 4Ω - 16Ω; 140Vrms and 200Vrms
• Cooling: Continuously variable speed forced air, front to back airflow
• Required AC Mains (±10%): 100V-240V ~ 50/60Hz
• Power Connector: 32A PowerCON
• Dimensions (W x H x D): 483 mm x 89 mm x 483 mm 19 in x 3.5 in x 19 in
• Weight: 13.15 kg (29.7 lbs)
• UPC: 691991009990
• Country of Origin: MX
