Description
DP 4EN is a unidirectional sound projector featuring an elegant aesthetic and easy orientation, suitable for the sonorization of commercial and industrial environments where a good sound quality and high intelligibility and efficiency are required. It features a cylindrical plastic body with aluminium grille and U-bracket support. Thanks to its IP55 protection grade, it can be installed both indoor and outdoor.
Features
- 4" fullrange transducer.
- Power selectable (100 V): 10 W - 5 W - 2.5 W.
- 91 dB sensitivity.
- Colour grey RAL 7035.
- Flameproof ABS body, aluminium grille and bracket.
- In/out ceramic terminal block.
- Thermal fuse protection.
- Protection grade IP55.
Specifications
| Acoustical specifications | |
| Frequency Response (-10dB) | 180 Hz - 16000 Hz |
| Max SPL @ 1m | 101 dB |
| Max SPL @ 4m | 89 dB |
| Coverage angle | 180° |
| System Sensitivity | 91 dB |
| System Sensitivity 1W @ 4m | 79 dB |
| Power section | |
| Power Handling | 10 W |
| Peak Power Handling | 40 W PEAK |
| Protections | Thermal fuse |
| Recommended Amplifiers | DXT 3000, DXT 4000, DXT 7000 |
| Transducers | |
| Fullrange | 1 x 4.0'' |
| Input/Output section | |
| Input connectors | Ceramic screw terminals |
| Output connectors | Ceramic screw terminals |
| Constant Voltage Transformer | 100 V |
| Power selection 1 | 10 W - 1000 ohm |
| Power selection 2 | 5 W - 2000 ohm |
| Power selection 3 | 2.5 W - 4000 ohm |
| Standard compliance | |
| IP protection grade | IP 55 |
| Safety agency | CE compliant |
| EN54-24 certified | Yes |
| CPR number | 0068-CPR-085/2017 |
| Physical specifications | |
| Cabinet/Case Material | ABS |
| Grille | Aluminium |
| Color | Grey - RAL 7035 |
| Size / Weight | |
| Depth | 200 mm / 7.87 inches |
| Diameter | 137 mm / 5.39 inches |
| Weight | 1.7 kg / 3.75 lbs |
| Shipping information | |
| Package Height | 290 mm / 11.42 inches |
| Package Width | 190 mm / 7.48 inches |
| Package Depth | 160 mm / 6.3 inches |
| Package Weight | 2.1 kg / 4.63 lbs |
